Autoquip Turntables
The Series 35 turntable is designed to provide workers with the ability to rotate their work to them, rather than walking around it. Units come either manual or powered to efficiently pallet build-up and tear-down. When used with an Autoquip lift table, these products further enhance both ergonomic and labor saving benefits by reducing reaching, bending, twisting and walking associated with palletizing operations.

KEY FEATURES

1/2" thick steel platform with radius
  corners
Turned, ground, polished & hard-chromed
  kingpin
Sealed-for-life ball bearing rollers
Bolt pin retainer with lifetime dry
  lubricated bushings
Rigid base frame with predrilled mounting
  holes
Minimum turntable size is 34" x 34"



BENEFITS

Minimal deflection
Maintenance-free bearings, no greasing
Simple to relocate
Increase production efficiency
Enhanced safety
Reduced worker-related fatigue

POWER SUPPLY
The manual Series 35 Turntable is operated by hand.
The Power Turntable is powered by a 1/4 hp, 115-230V/60 hz/ 1 ph motor. Controls are
  not supplied as standard.

CUSTOM DESIGNS
A number of "customized" engineering plans are already on file for the SR Series. Additionally, Autoquip offers computerized engineering services for development of "one-of-a-kind" manual and powered turntable applications.
